RYD2075BV01-A Graphic Lcd Display STN Blue Screen With Backlight High Brightness

Name: RYD2075BV01A Graphic Lcd Display STN Blue Screen With Backlight High Brightness
Brand: ROYAL DISPLAY
Price: 1 USD

China RYD2075BV01-A Graphic Lcd Display STN Blue Screen With Backlight High Brightness wholesale

Brand Name : ROYAL DISPLAY

Model Number : RYD2075BV01-A

Certification : SGS ROHS

Place of Origin : CHINA

MOQ : 500pcs

Price : Negotiable

Payment Terms : L/C, T/T, , L/C, Western Union, MoneyGram

Supply Ability : 10k/Month

Delivery Time : 25~28 Working Days

Packaging Details : 220pcs/CTN 11Kg L45*W36*H32CM, Cartons, Capboard, EPE, Blister Tray.

Product Name : Graphic LCD 128X64dots STN Gray Blue Film LCD Display Module

Model No. : RYD2075BV01-A

Display mode : STN-Blue, Transmissive, Posiive

LED Backlight : Blue

Display Format : 128x64dots

Viewing Angle : 6 O' clock

Controller IC : ST7565R

Operating Temp : -20º C~70º C

Connector : FPC

Sunlight Readable : Yes

Backlight Current (Typ) : 45mA

Connection : FPC-Soldering

Interface : serial/parallel

Contact Now

Graphic Lcd Display Gray Color Screen With Backlight High Brightness

General Specifications

1. Display Format 128x64 dots
2. Parallel interface
3. 5V power supply
4. Ultra high contrast, YG & White LED backlight as option
5. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option

Display Specifications

Item	Description
Product Name	128x64dots Graphic LCD Module
Model No.	RYG12864M
Dot Format(dot)	128x64
Outline Dimension(mm)	40.8x34.8
VA Size(mm)	37.7X25.1
AA Size( mm)	34.5x21.7
Viewing Angle	6 O' clock
LCD Mode	STN-Blue
Backlight	Blue
Driver IC	ST7565R
Power supply	3V or 5V
Interface	Parallel
Operating Temp	-20º C~70º C
Storage Temp	-30º C~80º C

Typical Applications

Clusters, Car Radios, Air conditioner, Home Automation, Industrial Instruments, etc

Features

Transmissive, Transflective and Reflective Mode

Wide Operation & Storage temperature range

Duty Ratio: up to 1:240

support gray scale display

FAQ

Q1. How can I get the samples?

A: If you need samples, we can make as per your request .You should pay the sample fee and freight. Sample lead time always be within 2-5 days.

Q2. How to order lcd?

A:Please send us your purchase order by Email, or ask us to send you one invoice. We need to know the following information for your order.

1)Product information-Quantity, part number

2)Delivery time required.

3)Shipping information-Company name, Street address,Phone&Fax number,Destination sea port.

4)Forwarder's contact details if you have any in China.

Q3. How long can I expect to get the sample?

A:The samples will be ready for delivery in 5~7days.The samples will be sent via express and arrive in 5~7 days.

Q4. When can I get the datasheet?

A: When we get your inquiry, you shall first tell us the part number you want, then we can send you the datasheet immediately.

Custom LCD/LCM are available
